Product Information
Description
HEWI Polyamide Nylon Straight Grab Bar with Inset Supports (Hafele: XXX.XX.XXX, HEWI: 950.36US1190) offers an eye-catching alternative to HEWI's standard two flange, straight grab bar solution. Inset perpendicular supports allow the gripping surface to remain completely parallel to the wall. This extremely sturdy bar features concealed flanges, and can be installed on flat walls with appropriate blocking. Polyamide plastic construction provides a smooth, durable finish.
- HEWI Number: 950.36US1190
- Hafele Number: XXX.XX.XXX
- ADA compliant (all finishes of this grab bar)
- 2-13/16" (71 mm) deep , 1-5/16" (33 mm) diameter tube, 1-1/2" (38 mm) clear space, 3-1/8" (80mm) diameter roses
- 250 lbs maximum load
- Requires mounting to wood studs or blocking
- Compatible with hanging seats 801.51US100 and 801.51US110
- Ideal for use in both dry and/or wet conditions
- Clean, minimalist design
- Unique alternative to grab bars with standard returns/supports
- Available in many lively colors
- Imported from Germany to order, not eligible for return
Material Color Charts - Click to Enlarge
Submittal Data - Click to View PDF
BIM Data - Click to View
